X-LARGE INOX AUTO BLOCK Carabiner

AISI 316 stainless steel connector with Auto Block sleeve. The X-Large is designed to offer a wide gate opening and a high tensile strength. The particular D shape prevents the rotation of the carabiner and allows to distribute the load along the major axis.
Fitted with Auto Block sleeve, easy to open even wearing gloves.
Equipped with Keylock system that prevents any snagging on the rope and in the bolts.
The Keylock system definitively eliminates any sealing tooth both on the body and on the gate of the connector.

There are therefore no points to snag rope or webbing being the carabiner devoid of sharp edges. Compared to other less noble stainless steels, AISI 316 steel is used in aggressive environments, where there are many corrosive factors that are prolonged over time, for example marine areas, saline environments, areas with the presence of chemical substances. It is therefore a perfect product for use in the nautical world but also in food and chemicals industry.

3 movements sleeve: to open the connector it is necessary to lift the sleeve, turn it and then pull the gate. High quality product completely developed and produced in Italy. Tested piece by piece.

Standards - EN 362/B
Material - Stainless Steel
Type - Keylock
Main Axis Load - 35kN
Minor Axis Load - /
Open Gate Load - /
Weight - 250g
Shape - Asymmetric

A. Length - 114mm
B. Width - 76.5mm
C. Body Diameter - 12mm
D. Eyelet Diameter - /
E. Gate Opening Diameter - 26mm

Sleeve - Auto Block
